Section 6. System Programming
6–49
QUESTIONS 37–49 SYSTEM REPORT CODES
L1 L2 L3 L4
1
st
digit 2
nd
digit 1
st
digit 2
nd
digit
event “a” event “b”
These questions enable the reporting of the event indicated on the EEPROM map if the value is not “A”
for single-digit events or “AA” for double-digit events. Selections can be 0–9, A–F. Refer to Section 8:
Central Station Reporting Formats for details on Contact ID
®
reporting codes. Use the separate
Programming Form to enter the actual values for each zone.
For each of the following questions, enter the digits as follows (except as noted):
L1 and L2: Enter the first and second digits of the report code for the listed event.
L3 and L4: Enter the first and second digits of the report code for the listed event.
L1 and L2
L3 and L4
Q 37 DURESS AC LOSS
Q 38 KEYPAD ✱ & # LOW BAT
Q 39* OPEN (L1) CLOSE (L2) RF JAM
Q 40 KEYPAD 7 & 9 PANIC KEYPAD 1 & 3 PANIC
Q 41 KEY TAMPER CS TEST
Q 42* FALSE ALARM
(exit error - L1, recent close - L2)
FALSE ALARM
(lockout - L3, cancel - L4)
Q 43 BELL/SIREN SUPERVISION KEYPAD TAMPER
Q 44* BYPASS
(bypass - L1, restore - L2)
TROUBLE
(fire trouble - L3, zone trouble -L4)
Q 45 DOWNLOAD WALK TEST
Q 46 EVENT LOG 90% FULL EVENT LOG 100% FULL
Q 47* RF SUPERVISION
(supervision - L1, tamper - L2)
RF SUPERVISION
(low battery - L3, trouble restore - L4)
Q 48 ARM DISABLE
(must be “DD” if disable
arming is set in Q 14, L3)
CLOCK SET
Q 49 UP-ABOUT CLOCK FAIL
* These questions have single-digit report code entries for each location. See Programming Form for
details.
