PC42E-T Desktop Printer User Guide 33
5. Push the tabs at each end of the printhead over the tab holders on the print and
ribbon mechanism.
6. Pull the printhead away from the printer and complete the following steps:
a. Disconnect the cables at each end of the printhead.
b. Use a Phillips screwdriver to remove the screw attached to the grounding
wire.
7. Remove the printhead from the printer.
8. Install the new printhead, starting with the following steps:
a. Connect the cables at each end of the printhead.
b. Use a Phillips screwdriver to secure the grounding wire and screw.
Tab
Tab Holder
Warning: Do not touch the printhead surface area.
