PRO3200 Installation
Setting Up the PRO3200 Hardware
PRO3200 (PRO32IC) Installation and Configuration Guide, Document 800-15494 13
3.3 Technical Specifications
Caution: Locate the power source as close to this board as possible. Connect power with minimum of
18AWG wires.
Note: POLARITY for 12 VDC power is important. Make sure the +12 VDC is connected to the
terminal labeled +12V and the return is connected to the terminal labeled GND.
Table 3 PRO3200 Technical Specifications
Category
Description
WARNING: PRO3200 is manufactured for use in
low-voltage, Class 2 circuits only.
Primary Power
12Vdc nominal with an operating range of 10 to 14Vdc., 300mA
maximum.
12Vdc @ 240mA (325mA with CoBox-Micro) nominal.
Memory and
Clock Backup
3Volts Lithium, type BR2325, BR2330, CR2330.
Ports
Port 0 10Base-T/100Base-TX Ethernet.
Port 1 RS-232 or 2-wire RS-485: 9,600 to 115,200
bps, async.
Port 2 & 3 2-wire RS-485: 2,400 to 38,400 bps, async.
Inputs
2 non-supervised, dedicated for cabinet tamper and power fault
monitoring.
Cable requirements
Power: 1 twisted pair, 18 AWG.
RS-485: 24AWG, 4,000ft (1,200m) maximum, twisted
pair with shield. 120 ohm.
RS-232: 24AWG, 25ft (7.6m) maximum.
Ethernet: Cat 5.
Alarm input: 1 twisted pair, 30 ohms maximum.
Environmental
Temperature: 0 to 49°C, operating
-55 to +85°C, storage
Humidity: 0 to 85% RHNC
Mechanical
Dimensions: 5.5 in. (137.7mm) W x 9 in. (228.6.4mm) L
x .75 in. (19.05mm) H
Weight: 7.1 oz. (201 gm) nominal
Specifications subject to change without notice.
