Revision 2 RMA803 Remote Indicator User's Guide 16
4.3 Configuration using Standard Display
For analog/HART transmitter, match the RMA801 parameters to the connected transmitter parameters
using the Standard Display menu.
The Remote Indicator’s two-button interface provides a user interface and an ability to configure the
display parameters. The figure below shows the location of the two-button option and the labels for
each button.
Figure 15: Two-Button Option
Table 3: Two-Button Functions
Physical
Button
Action Description
Menu 


Parameter
Selection and value
entry
Scroll to next menu item in an active
list.
Scroll through alphanumeric
parameter value list and change to
the desired value.
To return back to previous menu
Enter ↵
↵↵
↵
Entry confirmation
Enter to Main Menu from Normal PV
display.
Call up a lower-level menu.
Select an item for data entry.
Confirm a data entry operation
.
