Table 5: RMA801: Standard Display Menu
Parameter Parameter Values Desription
Menu
Operation
PV Display
[SEL PV]
Pressure (PRESURE)
Use the selection when RMA is
connected to Pressure transmitter
Press ↵ to
enter menu
selection
↓Menu to
select from
list
↵ to enter
Temperature (TEMP)
Use the selection when RMA is
connected to Temperature
transmitter
Loop Output (LOOPOUT) use the selection to show mA loop
current value in the RMA.
Percent Output (% OUT)
Use this selection to show %age
equivalent of mA loop current.
Pressure/
Temperature
Units [ UNIT]
Pressure Units:
inH2O@39°F
mH2O@4°C
cmH2O@4°C
torr mmH2O@68°F
ftH2O@68°F
inH2O@68°F
inH2O@60°F
atm
Pa, kPa, MPa
gf/cm2, kgf/cm2
psi
mbar, bar
inHg@0°C
mmHg@0°C
mmH2O@4°C
Temperature Units:
°C
°F
°R
K
mV
Ohm
Choose appropriate engineering
units from list as per Pressure or
Temperature PV selection.
Press ↵ to
enter Menu
selection
Menu to
select level.
↵ to Enter
Enter LRV
[ENTLRV]
Enter URV
[ENTURV]
#. ##
#. ##
The limits are:
-999999 to 999999
The LRV/URV value will be
available in Pressure/Temperature
Units (Standard Display Pressure/
Temperature unit)
Press ↵ to
enter menu
selection
↓ Menu to
select
number.
↵ to enter
and shift to
the next digit
to the right
NOTE:
ENTLRV & ENTURV should not be changed for STT700 DE device & STT250 DE device in both
digital and analog mode
