Sensepoint XCD RFD Technical Manual SPXCDHMRFEN Issue 4_08-2016
43
bumP
tESt

PEAK READING
DISPLAYED WITH OUTPUT
INHIBITED ‘ ’ ICON AND
PEAK STRING FLASHING.
APPLY BUMP TEST
GAS AND CHECK PEAK
READING ON DISPLAY.

CURRENT GAS
CONCENTRATION
DISPLAYED WITH
OUTPUT INHIBITED ‘ ’
ICON FLASHING.

UNIT RETURNS TO
MENU MODE
Forc
Curr

‘Forc’ DISPLAYED WITH ‘
’ ICON. DEFAULT FORCE
CURRENT ‘4.00’ FLASHES.
USE

TO CHANGE TO
REQUIRED mA LEVEL.

UNIT TRANSMITS THE
CURRENT
IF YOU WANT TO EXIT
FROM THIS MENU, USE
ABORT FUNCTION
SEt
ALrm

‘AL1’, ICON DISPLAYED
AND CURRENT ALARM
LEVEL 1 CONCENTRATION
FLASHES. USE

TO
CHANGE TO REQUIRED
CONCENTRATION LEVEL.

‘AL1’ DISPLAYED WITH
‘NonE’, ‘rISE’ OR ‘FALL’
FLASHING. USE

TO SELECT REQUIRED
ALARM ACTION.

‘AL2’, ICON
DISPLAYED
AND CURRENT
ALARM LEVEL 2
CONCENTRATION
FLASHES. USE

TO CHANGE
TO REQUIRED
CONCENTRATION
LEVEL.

‘AL2’ DISPLAYED WITH
‘NonE’, ‘rISE’ OR ‘FALL’
FLASHING. USE

TO SELECT REQUIRED
ALARM ACTION AND USE
‘

’ TO RETURN TO MENU
MODE.
Set
rLY

‘rL1’ DISPLAYED AND
‘AL1’, ‘AL2’, ‘Inht’ or ‘FLt’
FLASHES. USE

TO
CHANGE TO REQUIRED
RELAY TARGET.

‘rL1’ DISPLAYED
AND ‘dEEn’ or ‘Enr9’
FLASHES. USE

TO
CHANGE TO REQUIRED
RELAY ACTION.

‘Rl2’ DISPLAYED AND
‘AL1’, ‘AL2’, ‘Inht’ or
‘FLt’ FLASHES. USE

TO CHANGE TO
REQUIRED RELAY
TARGET.

‘rL2’ DISPLAYED AND
‘dEEn’ or ‘Encr9’ FLASHES.
USE

TO CHANGE
TO REQUIRED RELAY
ACTION.

‘rL3’ DISPLAYED AND
‘AL1’, ‘AL2’, ‘Inht’ or ‘FLt’
FLASHES. USE

TO
CHANGE TO REQUIRED
RELAY TARGET.

‘rL3’ DISPLAYED
AND ‘dEEn’ or ‘Enr9’
FLASHES. USE

TO
CHANGE TO REQUIRED
RELAY ACTION.

UNIT RETURNS TO
MENU MODE
rlY
OPr

‘rLY’, ‘ON’ DISPLAYED AND
CURRENT RELAY-ON TIME
FLASHES. USE

TO
CHANGE TO REQUIRED
RELAY-ON DELAY.

‘rLY’, ‘OFF’ DISPLAYED
AND CURRENT RELAY-
OFF TIME FLASHES.
USE

TO CHANGE
TO REQUIRED RELAY-
OFF DELAY.

‘Ltch’ DISPLAYED
AND ‘YES’ or ‘No’
FLASHES. USE

TO CHANGE TO
REQUIRED LATCH
OPTION.

UNIT RETURNS TO MENU
MODE
Set
Loc

‘Loc’ DISPLAYED WITH
FIRST 4 CHARACTERS OF
THE LOCATION STRING.
USE

TO CHANGE THE
1ST CHARACTER OF
CURRENT LOCATION
STRING. USE

TO MOVE
TO NEXT CHARACTER
AND SET REST OF
STRING. MAXIMUM 12
CHARACTERS CAN BE
SET.

‘Loc’ DISPLAYED NEW
LOCATION STRING. THE
STRING MOVES RIGHT-
TO-LEFT TO SHOW
WHOLE CHARACTERS
TWICE. THEN UNIT
AUTOMATICALLY
RETURNS TO MENU
MODE.
tEm
PUnIt

‘tEmP’ DISPLAYED WITH
‘°C’ OR ‘°F’ FLASHING.
USE

TO CHANGE TO
REQUIRED TEMPERATURE
UNIT.

UNIT RETURNS TO
MENU MODE
tES
tALrm

‘Forc’ DISPLAYED and ’AL1’
FLASHING TO SELECT
TEST-REQURED ALARM.
USE ‘

’ TO FORCE
ALARM1.

GAS NAME, CURRENT
GAS CONCENTRATION
DISPLAYED AND ‘
’ ICON AND AL ICON
FLASHE.

UNIT RETURNS TO
MENU MODE
9uIt

QUITS MENU MODE AND
RETURNS TO MONITORING
MODE

OK

OK

OK

OK

1
Refer to section 10.1 for detailed zero and span calibration procedures. Re-calibrate the detector if left un-powered for
periods in excess of 24 hours.
2
The calibration due warning counter is automatically reset after a successful calibration.
Table 12. Conguration Mode Operation
