SPYDER MODEL 7 VAV CONTROLLER INSTALLATION INSTRUCTIONS
3 31-00475-01
GENERAL
Trademark Information
• Spyder™ is a trademark of Honeywell International
Inc.
• BACnet® is a registered trademark of ASHRAE Inc.
• Sylk™ is a trademark of Honeywell International Inc.
Product Description
Honeywell’s Spyder Model 7 VAV controller is a
programmable room controller with an integrated
actuator and airflow sensor.
As a freely programmable VAV controller with universal
inputs and outputs, the Spyder Model 7 has
configuration flexibility to achieve a variety of specific
applications. Smart engineering and commissioning
tools with WEBs-N4 workbench and a mobile
application for test and balance make installation cost-
effective.
Spyder Model 7 offers BACnet IP or BACnet MSTP, Sylk™
bus technology, Modbus RTU RS-485, universal inputs
and output (UIO), and solid-state relays.
Controller Part Numbers
Fig. 1 Controller Part Numbers
Table 1 Part Numbers
Part Number Universal IO Solid State Relay
Total
IO
Communication
BLE
Integrated
WEB-VA75IB24NM 7 5 12 IP Yes
WEB-VA75I24NM 7 5 12 IP No
WEB-VA00IB24NM 0 0 0 IP Yes
WEB-VA75MB24NM 7 5 12 MSTP Yes
WEB-VA75M24NM 7 5 12 MSTP No
WEB-VA00MB24NM 0 0 0 MSTP Yes
Table 2 Replacement Part
Part Number Comments
SDPPF500PA Replacement air flow sensor
ANT-REM
Use the remote antenna if the antenna mounted on the controller does not provide
reliable communication due to environmental conditions. The packet contains four
antennas.
WEB - V
VAV
INTEGRATED ACTUATOR
BRAND IDENTIFIER
A75I B24NM
UNIVERSAL INPUTS
DIGITAL OUTPUTS (SSR)
MODBUS
NOT USED
POWER SUPPLY
BLE (Bluetooth)
IP/MSTP
