Honeywell ST 800 Quick Start Installation Guide

SmartLine Pressure Transmitter
4 Quick Start Installation Guide December 2016
Bracket Mounting
 Optional mounting bracket, see Figure 2
 Existing mounting bracket, see Figure 3
 Rotate the transmitter housing, see Figure 4
Level a transmitter with small absolute or differential pressure spans, see Figure 5.
Optional Mounting Bracket
Position the bracket on a 2-inch (50.8mm) and install “U” bolt around pipe and through
holes in bracket. Secure with nuts and lock washers provided.
Figure 2 Example - Angle mounting bracket secured to horizontal or vertical pipe.
Figure 2: Angle Mounting Bracket
