Honeywell STT25D User Manual

Smart Temperature Transmitter STT250 – Operator Manual 15
FIELD MOUNT HOUSING
WITH METER
RIGHT VIEW
FIELD MOUNT HOUSING
WITHOUT METER
RIGHT VIEW
FIELD MOUNT HOUSING
WITH OR WITHOUT
METER
FRONT VIEW
A
46188467-201
A
B
B
142
(5.59)
40
(1.57)
59.5
(2.34)
60
(2.36)
94
(3.7)115
(4.53)
Figure 7: Wall Mounting Dimensions
FIELD MOUNT HOUSING WITH
OR WITHOUT METER (
FRONT VIEW)
14,9
[0.59]
FIELD MOUNT HOUSING
WITH METER
(RIGHT VIEW)
FIELD MOUNT HOUSING
WITHOUT METER
(RIGHT VIEW)
14,9
[0.59]
CLEARANCE FOR CAP
REMOVAL
CLEARANCE FOR CAP
REMOVAL
A
B
A
B
142
[5.59]
40
[1.57]
191,5
[7.54]
60
[2.36]
61,8
[2.43]
39
[1.54]
94
[3.7]
115
[4.53]129,5
[5.1]
46188468-201
Figure 8: Pipe Mounting Dimensions
Dimensions Aluminium (field mount
housing)
316 Stainless Steel (field
mount housing)
A B A B
Without integral
meter
70 mm
[2.76 inch]
120,8 mm
[4.76 inch]
95,5 mm
[3.76 inch]
146,3 mm
[5.76 inch]
With integral meter 127 mm
[5.00 inch]
210,8 mm
[8.30 inch]
127 mm
[5.00 inch]
210,8 mm
[8.30 inch]
