Smart Temperature Transmitter STT250 – Operator Manual 25
MISCELLANEOUS PARTS
Adaptor plate to install module in field mount housing 46188423-501
Accessories kit (DIN rail clip, terminal screws, fail-safe link,
spring loading mounting set) 46188465-501
Spring loading mounting set 46188416-501
DIN rail mounting clip (top hat/"Ω" or "G" rail)
46188431-501
Carbon steel mounting bracket for 2" pipe
(for use with field mount housing)
30755905-001
Stainless steel mounting bracket for 2" pipe
(for use with field mount Housing)
30671907-001
1/2"NPT to M20 x 1.5 conduit adaptor (flameproof EEx d) 46188203-501 (Amiens)
Transient protector (external to housing) 30755970-501
Stainless steel wired-on customer ID tag 46188051-001
LITERATURE
SFC operating card 34-ST-11-16
English operator manual EN1I-6190
French operator manual FR1I-6190
Spanish operator manual SP1I-6190
5.4 Wiring and Installation Drawings Numbers
FM external wiring diagram 46188466-201
CSA external wiring diagram 46188466-202
Meter connections 46188461-201
Spring loading and sensor assembly 46188463-201
Pipe mounting dimensions 46188468-201
Wall mounting dimensions 46188467-201
Typical wiring of transient protector to STT250
transmitter
46188469-201
DIN rail mounting 46188464-201
Aluminium direct head mount housing 46188452-0XX
Cast-iron direct head mount housing 46188453-0XX
Stainless steel direct head mount housing 46188454-0XX
Plastic direct head mount housing 46188455-0XX
