Closing the Terminal Page 15
Closing the Terminal
To close the terminal, follow these steps:
1. Connect both contacts of the battery cable to the battery
2. Make sure that the rubber gasket is correctly positioned.
3. Close the terminal cover by rotating it.
4. Fasten the cover with the two special screws (see Figure 11) located on
the side of the terminal (use a TORX anti-tamper TX10 screwdriver).
Fasten the
special screws
INOUT
Figure 11: Closing the terminal
