Honeywell temaserver TS TA series User Manual

Jumpers Page 13
Jumpers
For normal operation, configure the jumpers on the main board as specified
in Table 2.
Jumper Function Default state
P10 auxiliary tamper Inserted
P12
auto-update of
firmware
Open
JP3 Ethernet full duplex Open
JP4 Ethernet loopback Inserted
Table 1: Configuration of jumpers on main board
Configure the jumpers on the display board as specified in Table 2.
Jumper Function Default state
JP2 data transmission
inserted between pins 1
and 2
JP3 data receipt
inserted between pins 1
and 2
Table 2: Configuration of jumpers on display board
