Page 8 Attaching the Terminal Support Plate

INSTALLATION

Attaching the Terminal Support Plate

To attach the terminal support plate, drill two holes in the wall in which to

place the plastic anchors that hold up the support plate (see Figure 4). Make

sure that the box attached to the wall is aligned with the niche on the

lower part of the support plate (use a ∅ 6mm parallel tip flat head

screwdriver).

anchor

Figure 4: Terminal support plate
