Page 18 TemaServer TS TAx3 (CTU-K03 code 1500064FA)
Inputs Number of inputs: 2
• opto-coupled mode
resistance: 2.2 Kohm
logic level high:
>4 V
DC
(max. positive +18 V
DC
)
logic level low:
<1 V
DC
(max. negative –0.5 V
DC
)
• self powered mode (dry contacts)
open contact: > 2Kohm
closed contact: < 100 ohm (10mA)
Regulations compliance
Directive EMC 89/336/EEC, 92/31/EEC,
Directive Low Voltage 72/23/EEC, 93/68/EEC:
EN60950, EN55024, EN55022, EN61000-3-2/3,
EN 300 330
Includes a part with FCC-ID: HS9-CTU-K03
Spare Parts
Fuses F1 : 2A 250V delayed
F2 : 1A 250V delayed
F3 : 1A 250V delayed
Battery 6V 1.2 Ah code 1801026
Figure 14: TemaServer TS TAx3
