Honeywell Voyager 1470g User Manual

Voyager XP User Guide 151
GS1 Emulation
The scanner can automatically format the output from any GS1 data carrier to
emulate what would be encoded in an equivalent GS1-128 or GS1 DataBar symbol.
GS1 data carriers include UPC-A and UPC-E, EAN-13 and EAN-8, ITF-14, GS1-
128, and GS1-128 DataBar and GS1 Composites. (Any application that accepts
GS1 data can be simplified since it only needs to recognize one data carrier type.)
If GS1-128 Emulation is scanned, all retail codes (U.P.C., UPC-E, EAN8, EAN13)
are expanded out to 16 digits. If the AIM ID is enabled, the value will be the GS1-
128 AIM ID, ]C1 (see Symbology Charts on page 213).
If GS1 DataBar Emulation is scanned, all retail codes (U.P.C., UPC-E, EAN8,
EAN13) are expanded out to 16 digits. If the AIM ID is enabled, the value will be the
GS1-DataBar AIM ID, ]em (see Symbology Charts on page 213).
If GS1 Code Expansion Off is scanned, retail code expansion is disabled, and UPC-
E expansion is controlled by the UPC-E0 Expand (page 135) setting. If the AIM ID
is enabled, the value will be the GS1-128 AIM ID, ]C1 (see Symbology Charts on
page 213).
If EAN8 to EAN13 Conversion is scanned, all EAN8 barcodes are converted to
EAN13 format.
Default = GS1 Emulation Off.
GS1-128 Emulation
GS1 DataBar Emulation
GS1 Code Expansion Off
EAN8 to EAN13 Conversion
* GS1 Emulation Off

Honeywell Voyager 1470g Specifications

General

Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Sealing	IP40
Motion Tolerance	Up to 70 cm/s (27.6 in/s) for 13 mil UPC at optimal focus
Storage Temperature	-40°C to 60°C (-40°F to 140°F)
Weight	130 g (4.6 oz)
Humidity	0% to 95% relative humidity, non-condensing
Scan Pattern	Omnidirectional
Connectivity	USB, RS-232, Keyboard Wedge
Decode Capability	Reads standard 1D
Drop Specification	Withstands multiple 1.5 m (5 ft) drops to concrete
Light Levels	0 to 100, 000 lux
Dimensions	62 mm x 169 mm x 82 mm (2.5 in x 6.6 in x 3.2 in)
Light Source	LED
