Honeywell Voyager 1470g User Manual

Voyager XP User Guide 199
*Storage outside of this temperature range could be detrimental to battery life.
CCB01-010BT-V1N Charge Base Product
Specifications
Vibration Withstands 5G peak from 5 to 300 Hz
ESD 12kV Air, 8kV contact
Image Size 1040 x 720 pixels
Scan Performance
Pitch, Skew ± 65°, ± 70°
Motion Tolerance:
Presentation Mode up to 70cm per second for 13 mil UPC
Print Contrast 20%
Parameter Specification
Parameter Specification
Dimensions (Typical):
Height 3.2 inches (8.13cm)
Length 5.19 inches (13.18cm)
Width 3.98 inches (10.11cm)
Weight 6.3 oz (179g)
Voltage: 4.5 to 5.5 volts
Current Draw:
Host Terminal Port 500mA
Aux Power Port 1A
Charge Time 5 hours
Radio:
Frequency 2.4 to 2.5 GHz (ISM Band) Frequency Hopping Bluetooth
v.4.2
Range 33 ft. (10 m) typical
Data Rate Up to 1 MBps
Temperature Ranges:
Operating 32° F to +122° F (0° C to +50° C)
Battery Charge 41° F to +104° F (5° C to +40° C)
Storage -40° F to +158° F (-40° C to +70° C)
Humidity Up to 95% non-condensing

Honeywell Voyager 1470g Specifications

General

Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Sealing	IP40
Motion Tolerance	Up to 70 cm/s (27.6 in/s) for 13 mil UPC at optimal focus
Storage Temperature	-40°C to 60°C (-40°F to 140°F)
Weight	130 g (4.6 oz)
Humidity	0% to 95% relative humidity, non-condensing
Scan Pattern	Omnidirectional
Connectivity	USB, RS-232, Keyboard Wedge
Decode Capability	Reads standard 1D
Drop Specification	Withstands multiple 1.5 m (5 ft) drops to concrete
Light Levels	0 to 100, 000 lux
Dimensions	62 mm x 169 mm x 82 mm (2.5 in x 6.6 in x 3.2 in)
Light Source	LED
