Honeywell Voyager 1470g User Manual

APPENDIX
A
Voyager XP User Guide 213
REFERENCE CHARTS
Symbology Charts
Note: “m” represents the AIM modifier character. Refer to International Technical
Specification, Symbology Identifiers, for AIM modifier character details.
Prefix/Suffix entries for specific symbologies override the universal (All Symbologies,
99) entry.
Refer to Data Edit beginning on page 93 and Data Format beginning on page 99
for information about using Code ID and AIM ID.
Linear Symbologies
AIM Honeywell
Symbology ID
Possible modifiers
(m)
ID Hex
All Symbologies 99
Codabar ]Fm 0-1 a 61
Code 11 ]H3 h 68
Code 128 ]Cm 0, 1, 2, 4 j 6A
Code 32 Pharmaceutical (PARAF) ]X0 < 3C
Code 39 (supports Full ASCII mode) ]Am 0, 1, 3, 4, 5, 7 b 62
TCIF Linked Code 39 (TLC39)
]L2 T 54
Code 93 and 93i ]Gm 0-9, A-Z,
a-m
i69
EAN ]Em 0, 1, 3, 4 d 64
EAN-13 (including Bookland EAN)
]E0 d 64
EAN-13 with Add-On
]E3 d 64
EAN-13 with Extended Coupon Code
]E3 d 64
EAN-8
]E4 D 44

Honeywell Voyager 1470g Specifications

General

Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Sealing	IP40
Motion Tolerance	Up to 70 cm/s (27.6 in/s) for 13 mil UPC at optimal focus
Storage Temperature	-40°C to 60°C (-40°F to 140°F)
Weight	130 g (4.6 oz)
Humidity	0% to 95% relative humidity, non-condensing
Scan Pattern	Omnidirectional
Connectivity	USB, RS-232, Keyboard Wedge
Decode Capability	Reads standard 1D
Drop Specification	Withstands multiple 1.5 m (5 ft) drops to concrete
Light Levels	0 to 100, 000 lux
Dimensions	62 mm x 169 mm x 82 mm (2.5 in x 6.6 in x 3.2 in)
Light Source	LED
