CHAPTER 15: VIDEO OBJECT
15.1 Video Object Overview
The Video Object feature allows two options for video type: Stream and Playback. The Video
Object trigger is used to start, stop, and pause video, and the System Register provides the
status of the video object, which supports various resolutions and frames per second.
Table 15.1 – Features and Specifications of Video Properties
Streaming Channels
4 channels supported through USB hub
1 channel can be viewed at a time
Playback Formats
.mp4
.mov
.mpg
.wmv
Resolution
320x240 (QVGA)
Frames per Seconds
10, 15, 20, 24, 30 & MAX_FPS
