6.3 Resource Limits
Table 6.3 – Resource Limits
Resource
Value
%S
13
%SR
192
%T
16000
%M
16000
%R
49999
%K
5
%D
1023
%I
2048
%Q
2048
%AI
512
%AQ
512
%IG
64 (per ID)
%QG
64 (per ID)
%AIG
32 (per ID)
%AQG
32 (per ID)
Ethernet
CsCAN, Ping, EGD, SRTP, Modbus TCP Master (Downloadable protocol) & Slave, Ethernet IP,
FTP, or HTTP @ 10MBd or 100MBd
CsCAN
125kBd, 250kBd, 500kBd, or 1MBd
Serial Ports
1 RS-232, 1 RS-485 Ports
IDs Per CsCAN
Network
64 w/o repeat (253 w/ 3 repeaters)
Keypad
5 keys (4 Function keys and a System Key)
Display
320 x 240 3.5” TFT, 64K colors
Screen Memory
64MB
User Screens
1023
Data Fields Per
User Screen
1023
Ladder Code
1024kB
