HORNER XL4 - Page 52

MAN0964-14-EN_XL4_XL4P_UM
N o v e m b e r 1 0 , 2 0 2 1 P a g e 52 | 194
Table 6.2 – %SR Registers – Master %SR Table
Register
Default I/O
Name
Description
Min-Max
Values
Program
(Read/Write)
Display
(Read/Write)
%SR6
Average Scan Rate ms ( / 10)
Read Only
Read Only
%SR7
Minimum Scan Rate ms ( / 10)
Read Only
Read Only
%SR8
Maximum Scan Rate ms ( / 10)
Read Only
Read Only
%SR9
TCH_PRESSURE
Current Touch Pressure
0 to 3000
Read Only
Read Only
%SR10
TCH_PRESSURE
_TSH
Threshold Touch Pressure
0 to 3000
Read/Write
Read/Write
%SR11-12
Ladder Size (32-Bit DINT)
Read Only
Read Only
%SR13-14
User Text Screen Size (32-Bit DINT)
*Excludes RCC Units
Read Only
Read Only
%SR15-16
System Text Screen Size (32-Bit DINT)
*Excludes RCC Units
Read Only
Read Only
%SR17-18
I/O Configuration Table Size (32-Bit
DINT)
Read Only
Read Only
%SR19-20
Network Config Table Size (32-Bit DINT)
Read Only
Read Only
%SR21-22
Security Data Table Size (32-Bit DINT)
Read Only
Read Only
%SR23
Ladder Code CRC
Read Only
Read Only
%SR24
User Text CRC
Read Only
Read Only
%SR25
System Text CRC
Read Only
Read Only
%SR26
I/O Configuration Table CRC
Read Only
Read Only
%SR27
Network Configuration Table CRC
Read Only
Read Only
%SR28
Security Data Table CRC
Read Only
Read Only
%SR29
NET_ID
Network ID
Read Only
Read / Write
CsCAN Mode
1 to 253
DeviceNet Mode
0 to 63
CANOpen Mode
1 to 127
%SR30
Network Baud Rate
0=125KB
1= 250kB
2= 5000KB
3= 1MB
4=50K
0 to 4
Read Only
Read/Write
%SR31
Network Required
0= Network not required
1= Network required;
2= Network optimized;
3= Network required and optimized
0 to 3
Read Only
Read Only
%SR32
LCD Display Contrast setting
*Excludes RCC Units
0 to 255
Read Only
Read/Write
%SR33
Function Key Toggle Mode
0= Momentary
1= Toggle
*Excludes RCC Units
0 to 1
Read/Write
Read/Write
%SR34
RS232 Serial Protocol Mode
0= Firmware Update (RISM)
1= CsCAN
2= Generic (Ladder- Controlled)
3= Modbus RTU
4= Modbus ASCII
Read Only
Read Only
%SR35-36
Unique Serial Number /
Hexadecimal LAN1 MAC ID
Read Only
Read Only
