%Q1651
Clear – Counter 4
%Q1652
Disable – Counter 4
%Q1653
Direction – C4
%Q1654
Output Reset – Counter 4
%Q1655
Preload Disable – Counter 4
%Q1656
Latch Disable – Counter 4
%Q1657-1664
Reserved
%I1601
Overflow Flag – Counter 1
%I1602
Underflow Flag – Counter 1
%I1603
High Speed Out 1
%I1604
Reserved
%I1605
Overflow Flag – Counter 2
%I1606
Underflow Flag – Counter 2
%I1607
High Speed Out 2
%I1608
Reserved
%I1609
Overflow flag – Counter 3
%I1610
Underflow flag – Counter 3
%I1611
High Speed Out 3
%I1612
Reserved
%I1613
Overflow flag – Counter 4
%I1614
Underflow flag – Counter 4
%I1615
High Speed Out 4
%I1616
Reserved
