48 Technical Service Manual M9 Transfer Stretcher (M999-29, Version 11, June 2021)
15. MISCELLANEOUS
1
86
11
16
19
5
3
9
4
15
14
10
17
7
18
12
13
19
2
ITEM NO. PART NO. DESCRIPTION QTY.
1 CRRM804 5944/150 COVERCLIP TRANSPARENT 2
2 CRRM805 LINEA WHEEL TENTE UAP150-5944 2
3 FXRM771 30mm CIRCLIP EXTERNAL DIN471 ZP 1
4 GNRM907 BEARING d30xD47xW9 SEALED MACHINED 2
5 M702-32 BRAKE TRANSMISSION LEVER 1
6 M801-60 CASTOR INSERT 2
7 M822-49 WHEEL NUT MALE 1
8 M822-50 WHEEL NUT FEMALE 1
9 M922-20 5TH WHEEL MOUNT PLATE M9 1
10 M922-21 5TH WHEEL ROTARY MOUNT M9 1
11 M922-22 5TH WHEEL SWING ARM M9 1
12 M922-26 5TH WHEEL LOCKING PIN M9 1
13 M922-27 5TH WHEEL ACTUATION ROD M9 1
14 M922-29 5TH WHEEL GAS STRUT TRUNION M9 1
15 NBRM3340 M10x20 CSK SKT SCREW SS 4
16 NBRM902 FLANGED PIVOT BOLT D23.8 x d14.8 x5.8 M10 2
17 SPRM351 GAS STRUT 525N 1
18 SPRM62 COMPRESSION SPRING 6x30x0.7x17 TURNS 1
19 WD40-861 SHORT PIVOT PIN SET 2
M922-01 5TH WHEEL COMPLETE
