Technical Service Manual M9 Transfer Stretcher (M999-29, Version 11, June 2021) 57
18. AMENDMENTS
PRE JUNE 2015- TRANSFER DECK COMPLETE
ITEM NO. PART NO. DESCRIPTION QTY.
1 ELRM9621 BACKREST ACTUATOR 1
2 ELRM9641 KNEE BREAK ACTUATOR 1
3 FXRM772 32mm EXTERNAL CIRCLIP ZP 2
4 M704-934 COVER PANEL BACKREST STRETCHER 1
5 M704-935 COVER PANEL KNEEBREAK STRETCHER 1
6 M710-10 POAG EARTH STUD 1
7 M904-11 DECK ASSEMBLY M9 TRANSFER 1
8 M904-47 CONTROL BOX COVER PLATE 3ED 1
9 M904-68 SOCKET BED END M9 STRETCHER DARK GREY 2
10 M908-45 PUSH HANDLE SUPPORT M9 STRETCHER 1
11 M928-01 IV POLE FOLD DOWN M9 STRETCHER 1
12 M928-20 IV POLE SADDLE M9 STRETCHER 1
13 N/A SEAT SECTION COMPLETE 1
14 N/A BACKREST COMPLETE STRETCHER 1
15 N/A KNEE BREAK & LEG RAISE COMPLETE 1
16 N/A 90mm FOOT END BUFFER GREY 2
17 N/A DECK STOP COMPLETE 4
18 N/A 90mm HEAD END BUFFER GREY 2
19 N/A BACKREST QR COMPLETE 1
20 N/A M9 TRANSFER MEDI RAIL AND CONTROL BOX ASSEMBLY 1
21 N/A CABLE BLOCK ASSEMBLY 2
22 N/A PUSH BAR ASSEMBLY 1
23 NBRM76 D10x40 M8 SKT SHLDR BOLT ZP 4
24 NBRM381 SELFTAP #8x3/4” PAN SQ SS 3
25 NBRM483 M8 NYLOC NUT ZP 5
26 NBRM4021 M6x8 BUTTON SKT SCREW SS 4
27 PLRM14 CABLE GROMMET 3+2 2
28 SPRM345 GAS STRUT 1
REFERENCE
See page 44
See page 54
See page 54
See page 49
See page 45
See page 49
See page 55
See page 47
See page 45
See page 50
TRANSFER DECK COMPLETE
