StartUp&Operation
17
EvaporatorPressureSetting
Model Temperature R‐404A
1000‐RLE 0°F 33PSI
2000‐RLE‐5°F 28PSI
3000‐RLE‐5°F 28PSI
EvaporatorPressureRegulator(EPR)
TheEPRwillholdthesuctiontemperatureat
theproperlevel,allowingforminor
adjustmentstobemadeusingtheThermostatic
ExpansionValve(TXV).
Eventhoughthesuctiontemperatureatthe
Evaporatoriscorrect,theTXVmaystillbe
underfeedingoroverfeeding.
AllEPRsareshipped
looseandmustbefield
installed.TheEPRshouldideallybelocated
within2feetoftheIceFlaker.
ToreadEPRsettinginstallservicemanifoldat
thePressureTapoftheEvaporatororatthe
inletoftheEPR.
ForAngleStyleEPR,removeendcapandadjust
usinga
1/4"hexwrench.
Toincreasethepressuresetting,rotate
clockwise.
Todecreasethepressuresetting,rotate
counter‐clockwise.
IfEPRfailstoregulatepressureproperly itmust
berepairedorreplaced.
ForGlobeStyleEPR,adjusttopstem.
Toensureanaccuratesetting,itisimportantto
setthe
EPRwhentheambienttemperatureat
theCondensingUnitis10°Fbelowthe
maximumratedambienttemperature.
