Howe 2000-RLE - Thermostatic Expansion Valve (TXV)



18

StartUp&Operation
ThermostaticExpansionValve(TXV)
AlwaysadjusttheEPRpriortoadjustingthe
TXV.

Superheatisnotareliablemethodofadjusting
TXVonIceFlaker.TXVmustbeadjustedwhile
visuallyinspectingtheEvaporator’sfreezing
surface.
ToincreasetherefrigerantfeedoftheTXV,
rotatestemcounterclockwise.
Todecreasethe
refrigerantfeedoftheTXV,
rotatestemclockwise.
TXVSensingBulb

Bulbplacementshouldbeatthe4:30position
ofaclockonthesuctionline.
AdjustingRefrigerationtotheIceFlaker
1. Visuallyinspectthefrostpatternonthe
freezingsurfaceoftheEvaporator.

IftheTXVisunderfeeding,
thetopof
thefrostpatternwillbeamilkywhite
colorandthebottomwillbeclear,soft,
andnotharvestproperly.


TXVUnderfeeding

2. IftheTXVisnotunderfeeding,closethe
TXVby1/4ofaturnandwait5
minutes.

3. Visuallyinspectthefrostpatternofthe
Evaporator.

4. Repeatsteps#2and#3until
underfeedingcanbeseenatthevery
bottomoftheEvaporator.

5. Now,
opentheTXVby1/4ofaturn and 
wait5minutes.

6. Repeatstep#5untiltheentirefrost
patternoftheEvaporatorbecomes
milkywhiteandharvestscompletely.

7. ConfirmcorrectEPRsetting.(see p.17)
