Howe 2000-RLE - Motor Overload Setting

StartUp&Operation


23

OverloadCondition
AnOverloadConditionbeginswhenthe
OverloadSensingCoilreadsamperagefromthe
motorleadpassingthroughitthatishigher
thantheMotorOverloadSetting.
DuringanOverloadConditionnovoltageis
presentatIceFlakerRunSwitchLeg(Term6),
theSolenoidValveContacts
(Term7&8)are
open,andtheOvercurrentConditionIndicator
Lightislitred.
TheMotorOverloadsettingshouldbeadjusted
onstart‐upandanytimechangesaremadeto
theDriveMotororMainShaft.






MotorOverloadSetting
TheproperadjustmentofMotorOverload
Settingwillprotect the
IceFlakerandhelpavoid
nuisanceservicecalls.
TosettheMotorOverloadcorrectly,
1. Markthelocationofthesetscrew
beforeanadjustmentismade,asa
pointofreference.

2. Placeasmallflatbladescrewdriverin
theadjustmentscrewwhiletheIce
Flakerisoperating.

3. Gently
andslowlyturn
counterclockwiseuntilOv erload
ConditionIndicationLightilluminates.
Donotforceadjustmentscrewpast
bottomstop.

4. Thenturnadjustmentscrewclockwise1
hashmarkandstop.

5. PresstheresetbuttontostarttheIce
Flakeragain.

 
