28

StartUp&Operation
TheAuxiliaryIceScraperslocatedatthetopand
bottom(2000‐RLEbottomonly)oftheIceBlade
removeanyiceforminginthoseareas.
TheclearanceoftheAuxiliaryIceScraper
shouldbethesameorslightlygreaterthanthe
IceBlade.
Squeegee
TheSqueegeewipesexcesswaterfromthe

freezingsurfacesothattheiceisdryupon
production.
TheSqueegeemus tbeinfullcontactwiththe
evaporatorfreezingsurface.
HavingaSqueegeenotincontactwiththe
freezingsurfacewillcreateweticewhichcauses
dragontheIceBlade.Thisputsgreaterstress
ontheSleeve
Bearingsandcausesthemtowear
fasterthannormal.

The1000‐RLEdoesnotfeatureaSqueegee.
Howeverithasalongerdryingtimebetween
IceBladepasses.
Withnormalusage,theSqueegeecanwear
overtime.WornSqueegeesneedtobe 
trimmedorreplaced.
GearMotor(1000‐RLE)
The
GearMotorisadrive motorandspeed
reducercombinedin onesingleunit.

Youshouldnevertrytoremovethemotoror
openthehousingoftheGearMotor.
OnemotorpowerleadfortheGearMotor
shouldpassthroughtheOverloadSensingCoil
ontheControlModuleno
lessthan(4)times.

TheGearMotorwillonlyfitintheenclosurein
theorientationshownabove.
 
