Hammer drill Wire stripper Hydraulic pliers
PV terminal
crimping tool
Tubular terminal
crimping tool
Network cable crimper
OT terminal
crimping tool
Heavy-duty connector
crimping tool
Phillips screwdriver
Protective goggles
Dust maskSafety gloves
Safety shoes
HAT-(5.0-10.0)HV-EUG1
Bracket*1 Communication Box*1 Double Row Plug*1
Document*1
Ground Terminal*1
M4 Setscrew*1
Battery Connector(+)*1
Battery Connector(-)*1
Inverter*1
Document
Accessories packing list
Smart Meter*1 CT*3
RJ45 Coupler*1
DTS*1
Optional (Wi-Fi, Ethernet, 4G)
EPS Connector*1
Grid Connector*1
Generator Connector*1
M6 Expansion Screw*4
Sleeve*4
M3 Setscrew*6
Communication Terminal*12
AC Terminal*15
EPS Connector Jacket*1
3.2 Installation Tools
The following tools are recommended in the installation process, and other auxiliary tools can also be used
on site if necessary.
