5.2 HAT-(5.0-10.0)HV-EUG1
Model HAT-5.0HV-EUG1 HAT-6.0HV-EUG1 HAT-8.0HV-EUG1 HAT-10.0HV-EUG1
Battery
Battery type Li-ion
Battery voltage range (V) 170-600
Max. charge/discharge current (A) 20/20 20/20 30/30 30/30
Max. charge/discharge power (W) 5000/5000 6000/6000 8000/8000 10000/10000
Charging strategy for Li-ion battery Self-adaption to BMS
Communication CAN, RS485
AC Input and Output (On-grid)
Rated output power (W) 5000 6000 8000 10000
Max. output apparent power (VA) 5500 6600 8800 11000
Max. input power (W) 10000 12000 16000 16000
Grid form 3L/N/PE
Rated AC output voltage/Range (V) 380/400, 266-480
Rated grid frequency (Hz) 50/60
Max. output current (A) 8.3 10.0 13.3 16.7
Max. input current (A) 15.2 18.2 24.2 24.2
Power factor >0.99 (0.8 leading ... 0.8 lagging)
THDi (@rated output) <3%
AC Output (Off-grid)
Rated output power (W) 5000 6000 8000 10000
Max. output apparent power (VA) 10000, 10s 12000, 10s 16000, 10s 16000, 10s
Back-up switch time (ms) <10
Grid form 3L/N/PE
Rated output voltage (V) 380/400
Rated output frequency (Hz) 50/60
Max. continuous output current (A) 8.3 10.0 13.3 16.7
THDv (@linear load) <3%
Efficiency
Max. efficiency 97.5% 97.5% 97.5% 97.5%
Protection
Anti-islanding protection Integrated
AC over current protection Integrated
AC short current protection Integrated
AC overvoltage and undervoltage protection Integrated
Surge protection DC Type II/AC Type III
General
Dimensions (W × H × D [mm]) 502 × 486 × 202
Weight (kg) 23
Mounting Wall mounting
Operating temperature (℃) -25 to +65 (>45, derating)
Relative humidity 0-95%, no condensing
Cooling Natural convection
Topology (Battery) Transformerless
Altitude (m)
≤
2000
Protection degree IP65
Noise (dB) <40
User interface LED, App
Digital input/output DRM, 1 × DI, 2 × DO
Communication RS485, optional: Wi-Fi/Ethernet/4G
(1)
Certifications and Standards
Grid connection standard EN 50549, VDE-AR-N 4105, AS/NZS 4777.2, VFR: 2019, TOR Erzeuger Type A
Safety/EMC standard IEC 62109-1/-2, IEC 62477-1, EN 61000-6-1/-3
(1) The DTS-4G solution will be coming soon.
