HP 1040 SERIES - Control Panel Overview

HP Fax basicsHP Fax basicsHP Fax basicsHP Fax basicsHP Fax basicsHP Fax basicsHP Fax basics
HP Fax basics 7
The HP Fax 1040/1050
Figure 2-3 Bottom view
Control Panel of HP FAX
Figure 2-4 Control panel of HP 1040 Fax
1 Connect handset to the
HANDSET port.
2 Connect telephone line
to the LINE port.
3 HP 1040 only: Connect
answering machine or
extension phone to the
EXT. port.
3
2
1
