SFORmat Subsystem
Introduction
The SFORmat subsystem contains the commands available for the State
Format menu in the HP
1650B/51B
logic analyzer. These commands are:
l
CLOCk
l
CPERiod
0
LABel
l
MASTer
l
REMove
0
SLAVe
l
THReshold
Figure 1
l-1.
SFORmat Subsystem Syntax Diagram
HP
1650B/HP
16518
Programming Reference
SFORmat Subsystem
11-l
