HP 1650B

RUNTil
RUNTil
Note d
command/query
The RUNTil (run until) command allows you to define a stop condition
when the trace mode is repetitive. Specifying OFF causes the analyzer to
make runs until either the STOP key is pressed or the STOP command is
issued.
There are four conditions based on the time between the X and 0
markers. Using this difference in the condition is effective only when time
tags have been turned on (see the TAG command in the STRace
subsystem). These four conditions are as follows:
l The diierence is less than (LT) some value.
l The difference is greater than (GT) some value.
l The difference is inside some range (INRange).
l The difference is outside some range (OUTRange).
End points for the INRange and OUTRange should be at least 10 ns apart.
There are two conditions which are based on a comparison of the
acquired state data and the compare data image. You can run until one of
the following conditions is true:
l Compare equal (EQUal) - Every channel of every label has the
same value.
l Compare not equal (NEQual) - Any channel of any label has a
different value.
The RUNTil query returns the current stop criteria.
The RUNTil instruction (for state analysis) is available in both the SLISt
and COMPare subsystems.
SLIST Subsystem
13-16
HP 1650B/HP 16518
Programming Reference
