HP Online Array Configuration Utility for NetWare 16
Menu option Result of selecting the option
Controller
Settings
A new panel opens, displaying settings for three
options: Rebuild Priority, Expand Priority, and
Accelerator Ratio.
Create New
Array
Three panels open:
Create Array (displays a menu with the following
options: Assign Drive, Assign Spare, Remove Drive,
and Accept Changes)
Physical Drives (lists the spare drives and
unassigned physical drives that are connected to
the controller)
New Array (shows the updated physical
configuration view)
• Array Options menu (appears in the secondary panel when an array is highlighted in the Logical
Configuration View panel)
Menu option Result of selecting the option
Expand Array Three panels open:
Expand Array (displays a menu with the following
options: Assign Drive, Remove Spare, and Accept
Changes)
Physical Drives (lists the spare drives and
unassigned physical drives that are connected to
the controller)
Expand Existing Array (shows the updated physical
configuration view)
Assign Spare
A new panel opens, displaying a menu of the valid
drives.
Remove Spare A new panel opens, displaying the spares.
Delete Entire
Array
The data and all the logical drive structures on the
array are deleted.
• Logical Drive Options menu (appears in the secondary panel when a logical drive is highlighted in
the Logical Configuration View panel)
Menu option Result of selecting the option
Delete
The data and the logical drive structure on the array
are deleted.
Drive Settings
A new panel opens, displaying settings for two
options: Fault Tolerance and Stripe Size.
SSP Settings*
A new panel opens, displaying the Enable or Disable
option.
*This menu option is available only with the MSA1000 and MSA1500.
Typical manual configuration procedures
This section describes the procedures for the following common tasks:
