● Touchpad cable (ZIF) (6)
● Backlight cable (ZIF) (7)
● Keyboard cable (ZIF) (8)
● Antenna cables from the WLAN module (9)
● Right speaker cable (10)
● USB/audio board cable (11)
5. Remove the 10 Phillips M2.0 × 3.0 screws (1), and the remove the system board (2).
46
Chapter 5 Removal and replacement procedures for authorized service provider parts
