b. Use tweezers to grasp the end of the stretchable tape that is installed under the OLED board.
While turning the tweezers (2), wrap the tape around the tweezers as you continue to pull the
tape out from behind the board, and then remove the board.
The OLED board is available as spare part number N86628-001.
13. To remove the camera cable:
a. Remove the cable from the clip (1) near the left hinge.
b. Peel the bottom of the cable (2) off the bottom of the display rear cover.
The camera cable is available as spare part number N86638-001
14. To remove the display cable:
a. Disconnect the cable from the connector (1) on the touch control board.
b. Disconnect the cable from the connector (2) on the OLED board.
c. Peel the cable (3) off the bottom of the display rear cover.
Display assembly
55
