HP 2530 SERIES

1-10
Introducing the Switch
Back of the Switch
Back of the Switch
Power Connector
These 24-port and 48-port switches do not have a power switch; they are
powered on when connected to an active AC power source. The switches
automatically adjust to any voltage between 100-127 and 200-240 volts and
either 50 or 60 Hz. There are no voltage range settings required.
AC power connector
HP 2530-24G-2SFP+ Switch (J9856A)
HP 2530-48G-2SFP+ Switch (J9855A)
HP 2530-24G-PoE+-2SFP+ Switch (J9854A)
AC power connector
HP 2530-48G-PoE+-2SFP+ Switch (J9853A)
