HP 2530 SERIES User Manual

A-4
Specifications
Cabling and Technology Information Specifications
Cabling and Technology Information
Specifications
Note on 1000BASE-T Cable Requirements. The Category 5 networking
cables that work for 100BASE-TX connections should also work for
1000BASE-T, as long as all four-pairs are connected. But, for the most robust
connections, you should use cabling that complies with the Category 5e
specifications, as described in Addendum 5 to the TIA-568-A standard (ANSI/
TIA/EIA-568-A-5).
Because of the increased speed provided by 1000BASE-T (Gigabit-T), network
cable quality is more important than for either 10BASE-T or 100BASE-TX.
Cabling plants being used to carry 1000BASE-T networking must comply with
the IEEE 802.3ab standards. In particular, the cabling must pass tests for
Attenuation, Near-End Crosstalk (NEXT), and Far-End Crosstalk (FEXT).
Additionally, unlike the cables for 100BASE-TX, the 1000BASE-T cables must
pass tests for Equal-Level Far-End Crosstalk (ELFEXT) and Return Loss.
Table A-2. Cabling Specifications
Twisted-pair copper
10 Mbps Operation Category 3, 4 or 5, 100-ohm unshielded twisted-pair (UTP) or
shielded twisted-pair (STP) cable, complying with IEEE 802.3
10BASE-T specifications.
100 Mbps Operation Category 5, 100-ohm UTP or STP cable, complying with IEEE
802.3u 100BASE-TX specifications.
1000 Mbps Operation Category 5, 100-ohm 4-pair UTP or STP cable, complying with
IEEE 802.3ab 1000BASE-T specifications—Category 5e or
better is recommended. See note on 1000BASE-T Cable
Requirements below.
Twinaxial copper
Direct attach cables One-piece devices consisting of a cable with SFP+ connectors
permanently attached to each end, complying with SFF 8431
SFP+ specifications.
Multimode fiber
62.5/125 m or 50/125 m (core/cladding) diameter, low metal
content, graded index fiber-optic cables, complying with the
ITU-T G.651 and ISO/IEC 793-2 Type A1b or A1a standards
respectively.
1
Single mode fiber
9/125 m (core/cladding) diameter, low metal content fiber-
optic cables, complying with the ITU-T G.652 and
ISO/IEC 793-2 Type B1 standards.
1
A mode conditioning patch cord may be needed for some Gigabit-LX installations.
See “Mode Conditioning Patch Cord” on page A-7 for more information.

HP 2530 SERIES Specifications

General

Model	HP 2530 Series
Category	Network Switch
Ports	8, 24, or 48 ports
Routing Protocol	Static routes
Management	Web interface, CLI, SNMP
Power Supply	Internal
PoE	Available on some models
Jumbo Frame Support	Yes
VLAN Support	Yes
Security Features	Port security, 802.1X
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 45°C
