HP 2920 User Manual

2-14
Installing the Switch
Installation Procedures
Rack Mounting the HP 2920 switch in a 4-post rack
1. Using the (J9583A) HP X410 E-Series 1U Universal Rack Mounting Kit,
use a #1 Phillips (cross-head) screwdriver and attach the slider brackets
to the switch with the included 8-mm M4 screws.
Figure 2-11. Attaching the rail kit slider brackets to the switch
2. Install the rails in the rack.
Figure 2-12. Installing the rails
3. Install the switch into the rails.
8 mm
M4 screws

HP 2920 Specifications

General

Layer	Layer 3
Power Device	Internal power supply
Ports	24 or 48 x 10/100/1000 ports
Stacking	Yes, up to 4 units
Management	Web, CLI, SNMP
Jumbo Frame Support	Yes
Routing Protocol	Static, RIP, OSPF
VLANs	4094
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	0°C to 45°C (32°F to 113°F)
Power over Ethernet (PoE)	Available on some models (PoE+)
