4-1
4
Replacing Components
This chapter shows you how to remove and install the following components:
Power Supply (see page 4-2)
10G Expansion Module (see page 4-3)
Stacking Module (see page 4-4)
Hot Swapping The HP 2920 10G Expansion Modules and the HP 2920 Stacking Module are
not hop swappable. The switch must be powered off before installing or
replacing any of these modules.
Caution The HP 2920 switches and their components are sensitive to static discharge.
Use an antistatic wrist strap and observe all static precautions when replacing
components.
Caution If a power supply must be removed and then reinstalled, wait at least 5 seconds
before reinstallation. Otherwise, damage to the switch may occur. The power
supply needs this time to bleed off any retained power.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP 2920 and is the answer not in the manual?

HP 2920 Specifications

General IconGeneral
LayerLayer 3
Power DeviceInternal power supply
Ports24 or 48 x 10/100/1000 ports
StackingYes, up to 4 units
ManagementWeb, CLI, SNMP
Jumbo Frame SupportYes
Routing ProtocolStatic, RIP, OSPF
VLANs4094
Power Supply100-240V AC, 50/60Hz
Operating Temperature0°C to 45°C (32°F to 113°F)
Power over Ethernet (PoE)Available on some models (PoE+)
