3-7
Getting Started With Switch Configuration
Using the IP Address for Remote Switch Management
The following illustration shows a typical web browser interface screen.
Figure 3-2. Example web browser interface screen
For more information on using the web browser interface, see the Manage-
ment and Configuration Guide, which is on the HP Networking web site at
www.hp.com/networking/support.
An extensive help system is also available for the web browser interface. To
access the help system though, the subnet on which the switch is installed
must have access to the internet, or HP IMC needs to be installed on a network
management station that is on the subnet.
Operating System Internet Explorer Java Version
Windows 2000 SP4 5.5 SP2, 6.0 SP1 1.3.1_12 and 1.4.2_05
Windows XP SP1a 6.0 SP1 1.3.1_12 and 1.4.2_05
Windows Server 2003 6.0 SP1 1.3.1_12 and 1.4.2_05

HP 2920 Specifications

General

Layer	Layer 3
Power Device	Internal power supply
Ports	24 or 48 x 10/100/1000 ports
Stacking	Yes, up to 4 units
Management	Web, CLI, SNMP
Jumbo Frame Support	Yes
Routing Protocol	Static, RIP, OSPF
VLANs	4094
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	0°C to 45°C (32°F to 113°F)
Power over Ethernet (PoE)	Available on some models (PoE+)
