HP StorageWorks 1000 Modular Smart Array installation guide 43

Connecting the MSA to SCSI storage enclosures

The following illustration shows the MSA1000 connected to two MSA30 SCSI storage enclosures.

NOTE: Tighten the thumbscrews on the SCSI cables to ensure a secure connection.

Figure 3 SCSI cable connections to two MSA30 SCSI storage enclosures
