HP 5120 EI Switch Series User Manual

17
You can configure an authorization attribute in user group view or local user view, making the attribute
effective for all local users in the group or only for the local user. The setting of an authorization attribute
in local user view takes precedence over that in user group view.
Local user configuration task list
Task
Remarks
Configuring local user attributes
Required
Configuring user group attributes
Optional
Displaying and maintaining local users and local user groups
Optional
Configuring local user attributes
Follow these steps to configure attributes for a local user:
To do…
Use the command…
Remarks
Enter system view
system-view
—
Set the password display mode for
all local users
local-user password-display-
mode { auto | cipher-force }
Optional
auto by default, indicating to
display the password of a local
user in the way indicated by the
password command.
Add a local user and enter local user
view
local-user user-name
Required
No local user exists by default.
Configure a password for the local
user
password { cipher | simple }
password
Optional
Place the local user to the state of
active or blocked
state { active | block }
Optional
When created, a local user is in
the active state by default, and
the user can request network
services.
Set the maximum number of users
using the local user account
access-limit max-user-number
Optional
By default, there is no limit on
the maximum number of users
that use the same local user
account.
This limit is not effective for FTP
users.
Configure the
password control
attributes for the
local user
Set the
password aging
time
password-control aging aging-
time
Optional
By default, the setting for the
user group is used. If there is no
such setting for the user group,
the global setting is used.
Set the minimum
password length
password-control length length
Optional
By default, the setting for the
user group is used. If there is no
such setting for the user group,
the global setting is used.

HP 5120 EI Switch Series Specifications

General

Model	HP 5120 EI Switch Series
Layer	Layer 3
Forwarding Rate	96 Mpps
MAC Address Table Size	16K
Power Supply	Internal
Management	CLI, Web GUI, SNMP
Features	IPv6 support
Routing Protocol	RIP, OSPF, BGP
Security Features	ACLs
Layer 3 Features	OSPF, BGP, VRRP
Redundancy	VRRP
Operating Temperature	0°C to 45°C
SFP Slots	4
VLAN Support	4094
Jumbo Frames	9216 bytes

Summary

AAA Configuration

RADIUS Protocol

HWTACACS Protocol

AAA Configuration Considerations and Task List

Outlines the tasks and considerations required for configuring AAA on a NAS device.

Configuring AAA Schemes

Details the process of configuring AAA schemes, including local, RADIUS, and HWTACACS schemes.

Configuring Local Users and Groups

Configuring RADIUS and HWTACACS Schemes

Describes configuring RADIUS and HWTACACS schemes, specifying servers, shared keys, and parameters.

Configuring AAA Methods for ISP Domains

Configuring AAA Authentication, Authorization, and Accounting Methods

Details the configuration of authentication, authorization, and accounting methods for users within an ISP domain.

802.1X Configuration

Configuring 802.1X

Provides steps for enabling 802.1X, setting access control, and configuring guest/Auth-Fail VLANs.

Enabling 802.1X and Access Control

Details enabling 802.1X globally and on ports, along with specifying access control methods.

MAC Authentication Configuration

MAC Authentication Configuration Task List

Lists tasks for configuring MAC authentication, including basic setup and examples.

Basic Configuration for MAC Authentication

Covers the basic steps for configuring MAC authentication globally and on ports.

MAC Authentication Configuration Examples

Portal Configuration

Configuring Layer 2 Portal Authentication

Details the steps to configure Layer 2 portal authentication, including VLAN assignment and Auth-Fail VLAN.

Portal Configuration Examples

Triple Authentication Configuration

Configuring Triple Authentication

Provides steps to configure triple authentication by enabling portal, MAC, and 802.1X authentication.

Triple Authentication Configuration Examples

Port Security Configuration

Port Security Features and Modes

Enabling Port Security and Setting Mode

Provides steps to enable port security and set its mode, like autoLearn or secure.

User Profile Configuration

User Profile Configuration Task List

Creating and Enabling User Profiles

Details creating and enabling user profiles to apply configurations and restrict user behaviors.

Password Control Configuration

Password Control Configuration Task List

Lists tasks for configuring password control, including global, group, and local user settings.

Configuring Password Control

Details enabling password control features like aging, history, and complexity checking.

Password Control Configuration Example

Public Key Configuration

Configuring the Local Asymmetric Key Pair

Details creating, destroying, displaying, and exporting local RSA or DSA key pairs.

Configuring a Peer Public Key

PKI Configuration

PKI Configuration Task List

Lists tasks for configuring PKI, including entity DN, PKI domain, and certificate requests.

Configuring an Entity DN and PKI Domain

Details configuring entity DN parameters and PKI domains for certificate requests.

Submitting and Retrieving Certificates

Explains submitting certificate requests in auto/manual modes and retrieving certificates.

Configuring PKI Certificate Verification

SSH2.0 Configuration

Configuring the Device as an SSH Server

Provides steps to configure the device as an SSH server, including key generation and user setup.

SSH Server Configuration Task List

Lists tasks for configuring the SSH server, such as key pair generation and enabling the server.

Configuring the Device as an SSH Client

Details configuring the device as an SSH client, including source IP and connection setup.

SSH Client Configuration Examples

SFTP Configuration

Configuring the Device as an SFTP Server

Provides steps to enable and configure the device as an SFTP server.

Configuring the Device an SFTP Client

Details configuring the device as an SFTP client, including source IP and connection setup.

SFTP Client Configuration Example

SFTP Server Configuration Example

SSL Configuration

SSL Configuration Task List

Configuring an SSL Server Policy

Details setting SSL parameters for a server, including PKI domain and cipher suites.

Configuring an SSL Client Policy

TCP Attack Protection Configuration

Enabling the SYN Cookie Feature

IP Source Guard Configuration

Static IP Source Guard Binding

Dynamic IP Source Guard Binding

Configuring IPv4 Source Guard Binding

Configuring IPv6 Source Guard Binding

ARP Attack Protection Configuration

ARP Attack Protection Configuration Task List

Configuring ARP Defense Against IP Packet Attacks

Configuring ARP Detection

ND Attack Defense Configuration

Enabling Source MAC Consistency Check for ND Packets

Configuring the ND Detection Function
