HP 5130 EI Switch Series User Manual

52
Switch model
Port mode
LED (Mode)
status
Double-color
(green and
yellow) LED
status
Description
Off The port is not supplying PoE.
•
The H P 513 0 -24G-2SFP+-2 X GT E I , H P 513 0 -24G-PoE+-2SFP+-2XGT (370W) EI, HP
513 0 -24G-4SFP+ EI, H P 513 0 -24G-4SFP+ EI BR, H P 513 0-24G-PoE+-4SFP+ (370W) EI, and HP
513 0 -24G-PoE+-4SFP+ (370W) EI BR switches provide two single-color LEDs for each
10/100/1000Base-T autosensing Ethernet port to indicate its operating status.
Table 24 Description for the two single-color LEDs for the 10/100/1000Base-T autosensing
Ethernet port
Switch model
Port mode
LED
(Mode)
status
LED Status Description
• H P 513 0 -24G-4SFP+ EI
• H P 513 0 -24G-4SFP+ EI
BR
• HP
513 0 -24G-2SFP+-2XGT
EI
N/A
Green LED
Steady on
The port is operating at
1000 Mbps, and a link is
present on the port.
Flashing
The port is sending or
receiving data at 1000
Mbps.
Off
No link is present on the
port, or the port is not
operating at 1000
Mbps.
Yellow LED
Steady on
The port is operating at
10/100 Mbps, and a
link is present on the port.
Flashing (not 3
Hz)
The port is sending or
receiving data at
10/100 Mbps.
Flashing
yellow (3 Hz)
The port has failed POST.
Off
No link is present on the
port, or the port is not
operating at 10/100
Mbps.
• HP
513 0 -24G-PoE+-4SFP+
(370W) EI
• HP
513 0 -24G-PoE+-4SFP+
(370W) EI BR
Steady
green (rate
mode)
Green LED
Steady on
The port is operating at
1000 Mbps, and a link is
present on the port.
Flashing
The port is sending or
receiving data at 1000
Mbps.
