HP 5130 EI Switch Series User Manual

53
Switch model
Port mode
LED
(Mode)
status
LED Status Description
•
HP
513 0 -24G-PoE+-2SFP+-2
XGT (370W) EI
Off
No link is present on the
port, or the port is not
operating at 1000
Mbps.
Yellow LED
Steady on
The port is operating at
10/100 Mbps, and a
link is present on the port.
Flashing (not 3
Hz)
The port is sending or
receiving data at
10/100 Mbps.
Flashing
yellow (3 Hz)
The port has failed POST.
Off
No link is present on the
port, or the port is not
operating at 10/100
Mbps.
Flashing
green (PoE
mode)
Green LED
Steady on
The port is supplying PoE
correctly.
Flashing (3 Hz)
• The PD power
requirement exceeds
the port PoE capacity.
• The port fails to meet
the power
requirement of the PD
because of power
insufficiency of the
switch.
Off
The port is not supplying
PoE power.
Yellow LED
Steady on
A non-PD device is
attached to the port, or
the port is experiencing a
PoE failure.
Flashing (3 Hz) The port has failed POST.
Off
The port is not supplying
PoE power.
1/10GBase-T autosensing Ethernet port LEDs
•
The H P 513 0 -48G-2SFP+-2XGT EI and H P 513 0 -48G-PoE+-2SFP+-2XGT (370W) EI switches provide
a double-color (green and yellow) LED for each 1/10GBase-T autosensing Ethernet port to indicate
its operating status.
