The OPERatioiuSETTling Node
This node gives a summary of the peltier settling nodes. Bit 0 returns the status
of the LPELTier node. Bit 1 returns the status of the HPELTier node. The
HPELTier node is only active for a dual wavelength source module, the other
modules use only LPELTier. A 1 means that the instrument is settling or has
settled. Bit 1 of the OPERation node summarizes this node.
The OPERation:SETTlmg:LPEmer Node
This node gives a summary of the peltier settling. Bit 0 returns the status of
the peltier settling of the module in channel A. Bit 1 returns the status of
the peltier settling of the module in channel B. A 1 means that the module is
settling or has settled. Bit 0 of the OPERation:SETTling node summarizes this
node.
The OPERationiSETTlmgsHPELTier Node
This node gives a summary of the peltier settling for the higher wavelength
of a dual wavelength source. Bit 0 returns the status of the peltier settling
for the higher wavelength of the module in channel A. Bit 1 returns the
status of the peltier settling for the higher wavelength of the module in
channel B. A 1 means that the module is settling or has settled. Bit 1 of the
C)PERation:SETTiing node summarizes this node.
The OPERationiMEASuring Node
This node gives a summary of the measuring status. Bit 0 returns the status of
the POWer node. Bit 4 of the OPERation node summarizes this node.
The OPEEation:MEASurmg:POWer Node
This node gives a summary of the power measurements. Bit 0 returns the
status of the power measuring of the module in channel A. Bit 1 returns
the status of the power measuring of the module in channel B. a 1 means
that a power measurement is taking place or has taken place. Bit 0 of the
OPERation:MEASuring node summarizes this node.
Rfimote Operation ■ Status Commands 7-11
