4-61
Remote Operation
CALCulate Subsystem Commands
CALCulate[1|2|3|4|5|6]:MATH:STATe OFF|ON|0|1
CALCulate[1|2|3|4|5|6]:MATH:STATe
Determines whether or not math processing is done.
CALCulate[1|2|3|4|5|6]:MAXimum:CLEar
Clears the current maximum hold values for the trace and allows a new maxi-
mum hold to occur. The trace will be initialized to a very negative dBm value
(–300 dBm). If the specified trace is not in the maximum hold state, this com-
mand will have no effect.
CALCulate[1|2|3|4|5|6]:MAXimum[:STATe] OFF|ON|0|1
CALCulate[1|2|3|4|5|6]:MAXimum[:STATe]?
Turns maximum hold on a trace
ON
or
OFF
. The maximum hold operation com-
pares the current amplitude value of each point on a trace in the current
sweep to the corresponding point detected during the previous sweep, then
stores the maximum value. The CALCulate:AVERage, CALCulate:MAXimum,
and CALCulate:MINimum states are mutually exclusive. Each trace can have
only one of these functions on at a time. Turning CALCulate:MAXimum
ON
will
automatically turn CALCulate:AVERage and CALCulate:MINimum
OFF
. Each
trace is allowed to have a different CALC block turned on. For example,
CALCulate1:MAXimum
ON
, CALCulate2:MINimum
ON
, CALCulate3:AVERage
ON
will put trace A in maximum hold, trace B in minimum hold and trace C in
trace average mode.
If the math expression with the corresponding CALCulate subopcode is
OFF
,
then the SENSe:DATA is used for the maximum hold operation. If the math
expression is
ON
, the result of the math expression is used for the maximum
hold operation.
book.book Page 61 Monday, January 31, 2000 10:34 AM
