4-72
Remote Operation
DISPlay Subsystem Commands
For each trace, except trace A:
Trace A is identical, except:
Sensitivity Set according to automeasure setup panel. In some cases, this
may also be a function of signal characteristics.
dB/div Set according to automeasure setup panel. In some cases, this
may also be a function of signal characteristics.
Video Bandwidth Auto
Auto Range Enable On
Trans-Z Lock Off
Repetitive Sweep On (front panel), Off (remote control)
Sweep Time Auto
Auto Chop Mode On
Gated Sweep Enable Off
Sweep Trigger Mode Internal
Trace Length 1001
Wavelength Limit On
Reference Level According to signal amplitude
Linear Display Mode Off
Resolution Bandwidth According to signal characteristics
Res-BW to Span Ratio 0.01
Peak Search on EOS Off
Line Markers Off
Trace Integration Limit Off
Search Limit Off
Trace Integration Off
Trace Mean Calculation Off
Trace Math Off
Update Off
View Off
Hold Mode None
Averaging Off
Update On
View On
