HP 86140A Series User Manual

4-74
Remote Operation
DISPlay Subsystem Commands
DISPlay[:WINDow[1]]:TRACe:X[:SCALe]:AUTO:SPAN <numeric_value>[M|NM|UM]
DISPlay[:WINDow[1]]:TRACe:X[:SCALe]:AUTO:SPAN?
Specifies the final span after a DISPlay:WINDow:TRACe:ALL:SCALe:AUTO
command.
DISPlay[:WINDow[1]]:TRACe:X[:SCALe]:AUTO:SPAN:AUTO ON|OFF|1|0
DISPlay[:WINDow[1]]:TRACe:X[:SCALe]:AUTO:SPAN:AUTO?
Specifies whether the final span after a DISPlay:WINDow:TRACe:ALL: SCALe:
AUTO command should be set automatically, based on properties of the mea-
sured signal.
DISPlay[:WINDow[1]]:TRACe:Y[:SCALe]:AUTO:PDIVision <numeric_value>[DB]
DISPlay[:WINDow[1]]:TRACe:Y[:SCALe]:AUTO:PDIVision?
Specifies the final vertical scale after performing a DISPlay:WIN-
Dow:TRACe:ALL:SCALe:AUTO command.
DISPlay[:WINDow[1]]:TRACe:Y[1|2][:SCALe]:AUTO:PDIVision:AUTO OFF|ON|0|1
DISPlay[:WINDow[1]]:TRACe:Y[1|2][:SCALe]:AUTO:PDIVision:AUTO?
Specifies whether the final vertical scale after a DISPlay:WIN-
Dow:TRACe:ALL:SCALe:AUTO command should be adjusted automatically,
based on signal properties. Y1 refers to the left (power) scale, and Y2 refers to
the right (ratio) scale.
DISPlay[:WINDow[1]]:TRACe:Y[1|2][:SCALe]:LINear OFF|ON|0|1
DISPlay[:WINDow[1]]:TRACe:Y[1|2][:SCALe]:LINear?
Specifies whether the vertical scale is in linear units or in log units. Y1 refers
to the left (power) scale, and Y2 refers to the right (ratio) scale.
book.book Page 74 Monday, January 31, 2000 10:34 AM
