HP 86140A Series User Manual

3-30
Using the Optical Spectrum Analyzer
The Markers Menus
To integrate between line markers
1
Press the front-panel
Markers
key.
2
Press the
More Marker Functions....
softkey.
3
Press the
Line Marker Menu....
softkey.
4
Select and set Wavelength Marker 1 and 2 to the desired integration limits.
5
Press the A
dvanced Line Mkr Functions
.... softkey.
6
Press the
Integrate Limit
softkey to toggle this function
ON
or
OFF
.
Turning the integration limit
ON
will calculate the power between Wavelength
Marker 1 and Wavelength Marker 2 when the Trace Integration function in
ON
.
See “To calculate the total power under a trace” on page 3-28.
To change the default marker settings
1
Press the front-panel
Markers
key.
2
Press the
More Marker Functions....
softkey.
3
Press the
Marker Setup....
softkey.
4
The Marker Setup panel opens. Refer to “To Fill In a Setup Panel” on page 3-65
for information on changing and selecting items in the setup panel.
Note
Although there is a single range controlling the total power integration, the marker
search range, and the wavelength sweep range, there are three independent state set-
tings for limiting the total power integration, the marker search, and the wavelength
sweep to the range.
book.book Page 30 Monday, January 31, 2000 10:34 AM
