Using Instrument Functions
Using Markers
When the maximum or minimum point is at or near either edge of the
display, the excursion requirement is satisEed by a half of a division excursion
on just one side of the maximum (or minimum). See Figure 4-9.
i/2 Division
-OdB-
4
Both Meet
End Peak
Criteria
Ppel Qc
Figure 4-9. Peak and Minimum Search Criteria at Display Endpoints
Connect a multi-pole Elter and press (MARKER) Max%er Saarch Ncsre and
Multi Peak if measuring a multi-pole bandpass Elter or HuT%iETotch if
measuring a multi-pole notch filter.
See Figure 4-10 and Figure 4-l 1 for examples of a multi-peak and a
multi-notch search, respectively.
